Key Technical Features
● 4-Channel Universal Input:
Supports up to 4 isolated channels with a fully configurable universal signal input interface. It directly accepts DC current, DC voltage, frequency, millivolt signals, thermocouples, RTDs (thermal resistance), and vacuum levels without requiring separate hardware converters.
● Integrated Multi-Outputs:
Configured with standard relay alarm outputs, transmission outputs, and built-in sensor power distribution loop power ($24\text{V DC}$) to power your field transmitters.
● Flow Totalizer & Reporting:
Includes onboard functions for flow totalization and automated production report generation, simplifying daily data tracking.
Visualization & Smart Interface
● Versatile Display Modes:
Engineered with a responsive UI that supports graphical trend curves, visual bar graphs, clear digital values, and comprehensive overview screens.
● Customizable Layouts:
Users can personalize trend curve colors and freely select between horizontal or vertical scrolling (paper-feed style) display orientations.
● Bilingual Localization:
Comes with a globally ready firmware interface allowing seamless 1-click switching between English and Chinese.
Storage, Connectivity & Software Integration
● Dual Data Storage Options:
Ensures zero data loss via a high-capacity internal SD card slot for backup, alongside a front-facing USB interface for easy historical data logging export to a USB flash drive.
● Industrial Networking & Printing:
Equipped with versatile communication interfaces, including RS485 (Modbus), GPRS, and Ethernet connections, plus support for on-site micro-printing and serial communication.
● DMR Data Analysis Software:
Pairs with the proprietary DMR PC host software, allowing users to perform remote data acquisition, real-time browsing, advanced statistical analysis, and multi-format reporting export.
